FG4412G-G5 4-GPU Server

Processor

Supports 2*4th or 5th generation Intel® Xeon® Scalable processors, with a maximum TDP support of 350W、Up to 64C/128T；

Chipset

Intel® C741；

Memory

16 DDR5 memory slots, supporting DDR5 4400/4800/5600MHz memory；

Supported GPU

Supports up to four double-width NVIDIA Tesla, Quadro, or RTX GPUs；

Network

2 RJ45 1GbE ；

Supports expansion with standard PCIe network adapters at 1GbE, 10GbE, 25GbE, 40GbE, 100GbE, and 200GbE. ；

Drive Bays Configuration

12 × 3.5-inch hot-swappable drive bays (compatible with 2.5-inch drives), 2 × M.2 slots, optional 4 × U.2 NVMe SSDs ；

RAID Expansion Support

Integrated SATA controller supporting SATA RAID 0/1/5/10(subject to system configuration)；

Configurable with SAS RAID controllers that support RAID 0,1,5,6,50,60,including supercapacitor-based cache protection.

PCI-Express

9 PCIe 5.0 x16 FHFL slots；

OS Compatibility

kylinos、Red Hat Enterprise Linux 、SLES、CentOS、QEMU-Xen、vSphere、QEMU-KVM、Ubuntu、VMWare ESXi、Microsoft Windows；

BMC

Integrated BMC management chip, supporting functions such as IPMI2.0, Redfish, SOL, KVM, virtual media, etc；

I/O Ports

1x IPMI RJ45 management port；

2x 1GbE RJ45 port；

1x VGA；

2x USB3.0 prot，2x USB2.0 port；

FAN

Standard 8 hot-swappable 8038 fans ；

Power Supply

2200W/2600W 1+1 redundant power supply ；

Chassis

4U Rackmount；

Security

Supports TPM2.0 module and chassis intrusion alarm；

Dimensions

437mm x 177mmx 760mm(WxHxD)；

Weight

Maximum weight 31 kg；

Operating Environment

Operating temperature: 5ºC - 35ºC (without direct sunlight);

Storage temperature: -40ºC - 70ºC；
