FG4812T-A4（4U 8-GPU Server）

Processor

Supports 2*AMD EPYC™9004/9005 series processors, with a maximum TDP support of 500W、Up to 192C/384T；

Memory

24 x DDR5 memory slots, each CPU supports 12 x memory channels, supporting up to 6400MT/s；

Supported GPU

Supports up to eight double-width NVIDIA Tesla, Quadro, or RTX GPUs；

Network

1 1Gb RJ45 dedicated management network port ；

Supports expansion with standard PCIe network adapters at 1GbE, 10GbE, 25GbE, 40GbE, 100GbE, and 200GbE；

Drive Bays Configuration

12 × 3.5-inch hot-swappable drive bays (compatible with 2.5-inch drives), 1 × M.2 slots, optional 2 × U.2 NVMe SSDs ；

RAID Expansion Support

Supports flexible configuration of SAS RAID controllers with RAID 0, 1, 5, 6, 50, and 60, featuring supercapacitor-backed cache protection .

PCI-Express

9 PCIe 5.0 x16 FHFL slots+2 PCIe 5.0 x8 FHFL slots；

OS Compatibility

kylinos、Red Hat Enterprise Linux 、SLES、CentOS、QEMU-Xen、vSphere、QEMU-KVM、Ubuntu、VMWare ESXi、Microsoft Windows；

BMC

Integrated BMC management chip, supporting functions such as IPMI2.0, Redfish, SOL, KVM, virtual media, etc；

I/O Ports

1x IPMI RJ45 management port；

2x VGA；

4x USB3.0 prot；

FAN

4 hot-swappable fan modules, supporting N+1 redundancy, intelligent speed regulation, and abnormal alarm ；

Power Supply

4x 2000W/2400W/2700W/3000W high-efficiency platinum power supply ；

Chassis

4/5U Rackmount；

Security

Supports TPM2.0 module and chassis intrusion alarm；

Dimensions

448mm x 175mmx 822mm(WxHxD)；

Weight

Maximum weight 31 kg；

Operating Environment

Operating temperature: 5ºC - 35ºC (without direct sunlight);

Storage temperature: -40ºC - 70ºC；
